B840M DS3H
B840M DS3H
- İşlemciİşlemci
- AMD Socket AM5, support for: AMD Ryzen™ 9000 Series Processors/ AMD Ryzen™ 8000 Series Processors/ AMD Ryzen™ 7000 Series Processors
(En son CPU destek listesi için GIGABYTE'ın web sitesine gidin) - AMD Socket AM5, support for: AMD Ryzen™ 9000 Series Processors/ AMD Ryzen™ 8000 Series Processors/ AMD Ryzen™ 7000 Series Processors
- YongasetiYongaseti
- AMD B840
- AMD B840
- BellekBellek
- 4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity) of system memory
- Support for DDR5 8200(O.C) / 8000(O.C) / 7950(O.C) / 7900(O.C) / 7800(O.C) / 7600(O.C.) / 7400(O.C.) / 7200(OC)/7000(OC)/6800(OC)/6666(OC)/6600(OC)/6400(OC)/6200(OC)/ 6000(OC)/5600(OC)/5200/4800/4400 MT/s memory modules
- Çift kanal bellek mimarisi
- ECC olmayan DIMM 1Rx8/2Rx8/1Rx16 hafıza modüllerini destekler
- Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory modules
(The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to "Memory Support List" on GIGABYTE's website for more information.) - 4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity) of system memory
- Dahili GrafikDahili GrafikIntegrated Graphics Processor - AMD Radeon™ Graphics support
- Maksimum 4096x2160 @ 60 Hz çözünürlüğü destekleyen 1 x HDMI bağlantı noktası
* Support for HDMI 2.1 version, HDCP 2.3, and HDR.
** Support native HDMI 2.1 TMDS compatible ports. - 2 x DisplayPorts, supporting a maximum resolution of 3840x2160@144 Hz
* Support for DisplayPort 1.4 version.
Support for up to triple-display at the same time(Graphics specifications may vary depending on CPU support.) - Maksimum 4096x2160 @ 60 Hz çözünürlüğü destekleyen 1 x HDMI bağlantı noktası
- Ses DesteğiSes Desteği
- Realtek® audio codec
- HD Ses Desteği
- 2/4/5.1/7.1-kanal
* You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.
- Realtek® audio codec
- LANLAN
- Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
- Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
- Genişleme YuvalarıGenişleme Yuvaları1 x PCI Express x16 slot (PCIEX16), integrated in the CPU
- AMD Ryzen™ 9000/7000 Series Processors support PCIe 4.0 x16 mode
- AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode
- AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode
- (The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot.)
Chipset- 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x4 (PCIEX4)
- AMD Ryzen™ 9000/7000 Series Processors support PCIe 4.0 x16 mode
- Depolama Ara yüzüDepolama Ara yüzü
- 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2580/2280 SSDs:
AMD Ryzen™ 9000/7000 Series Processors support PCIe 4.0 x4/x2 SSDs
AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs
AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs - 1 x M.2 connector (M2B_CPU), integrated in the CPU, supporting Socket 3, M key, type 25110/22110/2580/2280 SSDs:
AMD Ryzen™ 9000/7000 Series Processors support PCIe 4.0 x4/x2 SSDs
AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs
AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x2 SSDs - 4 x SATA 6Gb/s konektörler
RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices* RAID 5 is only available on AMD Ryzen™ 9000 Series Processors.
RAID 0, RAID 1, and RAID 10 support for SATA storage devices - 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2580/2280 SSDs:
- USBUSBİşlemci
- 1 x USB Type-C® port, with USB 3.2 Gen 1 support on the back panel
- 1 x USB 3.2 Gen 1 port on the back panel
CPU+USB 2.0 Hub- 4 x USB 2.0/1.1 ports on the back panel
Yongaseti- 1 x USB Type-C® port with USB 3.2 Gen 1 support, available through the internal USB header
- 3 x USB 3.2 Gen 1 ports (1 port on the back panel, 2 ports available through the internal USB header)
- 4 x USB 2.0/1.1 yuva dahili USB bağlantısı ile
- 1 x USB Type-C® port, with USB 3.2 Gen 1 support on the back panel
- Dahili G/Ç Bağlantı NoktalarıDahili G/Ç Bağlantı Noktaları
- 1 x 24-pin ATX ana güç konektörü
- 1 x 8-pin ATX 12V güç konektörü
- 1 x CPU Fan konektörü
- 1 x CPU fan/water cooling pump header
- 1 x sistem fan başlığı
- 1 x sistem fan/sıvı soğutma pompa başlığı
- 2 x addressable RGB Gen2 LED strip headers
- 1 x RGB LED şerit başlığı
- 4 x SATA 6Gb/s konnektörü
- 2 x M.2 Socket 3 konnektörler
- 1 x ön panel başlığı
- 1 x ön panel ses başlığı
- 1 x USB Type-C® header, with USB 3.2 Gen 1 support
- 1 x USB 3.2 Gen 1 header
- 2 x USB 2.0 / 1.1 başlıkları
- 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 / GC-TPM2.0 SPI V2 module only)
TPM özeliği, bölgesel kuralların farklılığı nedeniyle opsiyonel olabilir - 1 x reset jumper
- 1 x Clear CMOS bağlayıcı teli
- 1 x 24-pin ATX ana güç konektörü
- Arka Panel G/ÇArka Panel G/Ç
- 1 x HDMI bağlantı noktası (Not:)
- 2 x DisplayPorts (Note)
- 1 x Q-Flash Plus button
- 1 x PS/2 Klavye/Fare bağlantı noktası
- 1 x USB Type-C® port, with USB 3.2 Gen 1 support
- 2 x USB 3.2 Gen 1 ports
- 4 x USB 2.0/1.1 yuva
- 1 x RJ-45 bağlantı noktası
- 3 x ses jakı
(Not) Gerçek destek CPU'ya göre değişebilir. - 1 x HDMI bağlantı noktası (Not:)
- G/Ç DenetleyicisiG/Ç Denetleyicisi
- iTE® I/O Kontrol Yongası
- iTE® I/O Kontrol Yongası
- Donanım İzlemeDonanım İzleme
- Voltaj dedektörü
- Sıcaklık dedektörü
- Fan hız dedektörü
- Su soğutma akış hızı algılama
- Fan hatası uyarısı
- Fan hız kontrolü
* Fan (pompa) hız kontrolü fonksiyonunun desteklenip desteklenmediği, kurduğunuz fan (pompa) 'ya bağlıdır.
- Voltaj dedektörü
- BIOSBIOS
- 1 x 256 Mbit flash
- Lisanslı AMI UEFI BIOS kullanımı
- PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
- 1 x 256 Mbit flash
- Diğer ÖzelliklerDiğer Özellikler
- Support for GIGABYTE Control Center (GCC)
*Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. - Q-Flash desteği
- Q-Flash Plus desteği
- Support for Smart Backup
- Support for GIGABYTE Control Center (GCC)
- Bundled SoftwareBundled Software
- Norton® Internet Security (OEM versiyon)
- LAN bandwidth management software
- Norton® Internet Security (OEM versiyon)
- İşletim Sistemiİşletim Sistemi
- Support for Windows 11 64-bit
- Windows 10 64-bit desteği
- Support for Windows 11 64-bit
- Form FaktörForm Faktör
- Mikro ATX Form Faktörü; 24,4 cm x 24,4 cm
- Mikro ATX Form Faktörü; 24,4 cm x 24,4 cm
