A620I AX

(rev. 1.0)
TanıtımDestek
A620I AX
  • İşlemci
    İşlemci
    1. AMD Socket AM5, support for: AMD Ryzen™ 7000 / Ryzen™ 8000 / Ryzen™ 9000 Series Processors
    (Daha fazla bilgi için "İşlemci Destek Listesine" bakınız.)
  • Yongaseti
    Yongaseti
    1. AMD A620
  • Bellek
    Bellek
    1. Support for DDR5 6400(OC)/6200(OC)/6000(OC)/5600(OC)/5200/4800/4400 MT/s memory modules
    2. 2 x DDR5 DIMM sockets supporting up to 128 GB (64 GB single DIMM capacity) of system memory
    3. Çift kanal bellek mimarisi
    4. ECC olmayan DIMM 1Rx8/2Rx8/1Rx16 hafıza modüllerini destekler
    5. Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory modules
    (The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to "Memory Support List" on GIGABYTE's website for more information.)
  • Dahili Grafik
    Dahili Grafik
    Integrated Graphics Processor - AMD Radeon™ Graphics support
    1. 1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz
      * Support for DisplayPort 1.4 version.

    2. Maksimum 4096x2160 @ 60 Hz çözünürlüğü destekleyen 1 x HDMI bağlantı noktası
      * Support for HDMI 2.1 version and HDCP 2.3.
      ** Support native HDMI 2.1 TMDS compatible ports.

    (Graphics specifications may vary depending on CPU support.)
  • Ses Desteği
    Ses Desteği
    1. Realtek® audio codec
    2. HD Ses Desteği
    3. 2/4/5.1/7.1-kanal
      * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.

  • LAN
    LAN
    1. Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
  • Wireless Bağlantı Modülü
    Wireless Bağlantı Modülü
    Realtek® Wi-Fi 6E RTL8852CE
    1. WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
    2. BLUETOOTH 5.3
    3. Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
    (Actual data rate may vary depending on environment and equipment.)
  • Genişleme Yuvaları
    Genişleme Yuvaları
    1 x PCI Express x16 slot, integrated in the CPU
    1. AMD Ryzen™ 7000 Series Processors support PCIe 4.0 x16 mode
    2. AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode
    3. AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode
      * The PCIEX16 slot can only support a graphics card or an NVMe SSD.

  • Depolama Ara yüzü
    Depolama Ara yüzü
    1 x M.2 connector, integrated in the CPU, supporting Socket 3, M key, type 2280 SSDs:
    1. AMD Ryzen™ 7000 Series Processors support PCIe 4.0 x4/x2 SSDs
      AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs
      AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs

    2. 2 x SATA 6 Gb / s konektörleri
    RAID 0 and RAID 1 support for NVMe SSD storage devices
    RAID 0 and RAID 1 support for SATA storage devices
  • USB
    USB
    İşlemci
    1. 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 1 support
    2. 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel
    3. 1 x USB 2.0/1.1 port on the back panel
    Yongaseti
    1. 1 x USB Type-C® port with USB 3.2 Gen 1 support, available through the internal USB header
    2. 3 x USB 3.2 Gen 1 ports (1 port on the back panel, 2 ports available through the internal USB header)
    3. 4 x USB 2.0/1.1 port (2 port arka panelde, 2 port dahili USB bağlantı ile)
  • Dahili G/Ç Bağlantı Noktaları
    Dahili G/Ç Bağlantı Noktaları
    1. 1 x 24-pin ATX ana güç konektörü
    2. 1 x 8-pin ATX 12V güç konektörü
    3. 1 x CPU Fan konektörü
    4. 2 x Sistem fan konektörü
    5. 1 x adreslenebilir LED şerit başlığı
    6. 1 x RGB LED şerit başlığı
    7. 1 x M.2 Soket 3 konektör
    8. 1 x Ön panel konektörü
    9. 1 x Ön panel ses konektörü
    10. 1 x hoparlör bağlantısı
    11. 1 x USB Type-C® header, with USB 3.2 Gen 1 support
    12. 1 x USB 3.2 Gen 1 header
    13. 1 x USB 2.0/1.1 başlığı
    14. 1 x Clear CMOS bağlayıcı teli
    15. 1 x kasa izinsiz giriş önleme bağlantısı
  • Arka Panel G/Ç
    Arka Panel G/Ç
    1. 1 x DisplayPort bağlantı noktası
    2. 1 x HDMI bağlantı noktası
    3. 1 x USB Type-C® port, with USB 3.2 Gen 1 support
    4. 1 x USB 3.2 Gen 2 Type-A port (red)
    5. 1 x USB 3.2 Gen 1 port
    6. 3 x USB 2.0/1.1 port
    7. 1 x Q-Flash Plus button
    8. 1 x RJ-45 bağlantı noktası
    9. 2 x SMA anten konnektörleri (2T2R)
    10. 3 x ses jakı
  • G/Ç Denetleyicisi
    G/Ç Denetleyicisi
    1. iTE® I/O Kontrol Yongası
  • Donanım İzleme
    Donanım İzleme
    1. Voltaj dedektörü
    2. Sıcaklık dedektörü
    3. Fan hız dedektörü
    4. Su soğutma akış hızı algılama
    5. Fan hatası uyarısı
    6. Fan hız kontrolü
      * Fan hızı kontrol fonksiyonunun desteklenip desteklenmediği, taktığınız fana bağlı olacaktır.

  • BIOS
    BIOS
    1. 1 x 256 Mbit flash
    2. Lisanslı AMI UEFI BIOS kullanımı
    3. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
  • Diğer Özellikler
    Diğer Özellikler
    1. Support for GIGABYTE Control Center (GCC)
      *Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
    2. Q-Flash Plus desteği
  • Bundled Software
    Bundled Software
    1. Norton® Internet Security (OEM versiyon)
    2. LAN bandwidth management software
  • İşletim Sistemi
    İşletim Sistemi
    1. Support for Windows 11 64-bit
    2. Windows 10 64-bit desteği
  • Form Faktör
    Form Faktör
    1. Mini-ITX Form Faktör; 17.0cm x 17.0cm
